Bestcare - What System Does My Patient Lift Use? 0

You can understand what system your lift uses by looking at its serial number.





Here's an example of a Serial Number: SA600EL17050100

 Please use the following guide to understand your serial number:

 SA
Type of lift. Can start with PL(patient lift) SA(sit-to-stand) and STA(standing-transfer-aid)
600
Weight capacity (400/500/600 available)
EL

Model (This sequence is not on every serial number. Older units circa 2017 or older may include this but with possible conversions to another unit such as PL400EL->PL400E makes this sequence obsolete.

17 Production Year
05 Production Month
01 Production Plant (0/1/2/9 available)
000 Batch Number





TiMotion System

If the customers have a Production plant number of 1 or 2 they WILL have newer TiMotion electronic system and will require those parts.



Performance and Legacy System

We introduced the Performance system in the 3rd quarter of 2013. So, from Sept 2013 to January 2017, we were selling both lifts with Legacy and Performance systems. In 2017, we stopped selling Legacy lifts but do have dealers that stocked their own inventory so it’s possible a customer may order a lift later that same year and have older electronic. There were also many conversions between the two when inventory was low so for older lifts it will be best to makes sure they match up by their control box picture to distinguish between Performance and Legacy System.



For customers that have a Production plant number of 0 and Production year of 2012 or older they will most likely have Legacy electronics.



  • Christopher Wei

Bestcare - What Control Box / Charger / Hand Control / Batteries Do I Need For My Patient Lift? 0

Sometimes it can be difficult to understand what compatible parts you need for your patient lift. However, there is a simple method to understand what to get. Many Bestcare patient lift models have versions that utilize different electronic components. However, it is easy to recognize what electronic parts you need, based on the control box at the back of your lift. There are three models: The Performance Control Box, The Legacy Control Box, and the TiMotion Control Box. Here is how you can understand what control box your lift uses and thus, what charger/hand control/batteries you will need.
  • Christopher Wei
